Spectrum Pro RGB-W Rock Light Installation Guide

Spectrum Pro RGB-W Rock Light Installation Guide

This guide covers the full installation of the ALTIQ™ Spectrum Pro RGBW Rock Light kit: mounting, wiring, connector handling, and app pairing. It applies to both the 6-pack and 8-pack configurations.

What's Included

  • 6 or 8 x Spectrum Pro RGBW LED Rock Lights
  • 6 or 8 x Flat Rubber Mounts
  • Mounting bolts and self-tapping screws
  • 1 x Bluetooth RGBW LED Control Box
  • 1 x Wiring Harness (switch & in-line fuse included)



Step 1: Mounting

Plan your mounting positions for all lights before fastening anything. Consider where cables will run from each position back to the Control Box, and whether you'll be routing through existing holes or creating new ones.

Each Spectrum Pro uses a single-bolt mounting system through the centre of the light. Two fastener options are included. Select based on your mounting location:

  • Machine Screw: use where you have rear access to the mounting surface. Secure with the Washer, Split Washer, and Nut.
  • Self-Drilling Screw: use where rear access is not possible. Confirm there is nothing behind the surface before drilling. Secure with the Shoulder Washer.

Where possible, use existing holes or factory mounting points on the chassis, bash plates, or bumper brackets to avoid drilling into structural components.

Flat Rubber Mounts are included, however if you prefer, 30° Rubber Mounts are available separately.

Warning: Do not overtighten. Maximum torque is 15Nm. Exceeding this will damage the light.

Once secured, press the waterproof Rubber Cap into the centre screw hole and snap the Optic Cover into place. Repeat for all lights in the kit.

Wire Routing

The Rubber Mount supports two cable exit configurations:

  • Rear Exit: cable exits through the back of the mount, suited to panel mounting where the cable runs behind the surface.
  • Surface Mount: cable exits through the bottom, suited to exposed or external mounting positions.


Step 2: Wiring

Route cables from each light along the chassis towards the Control Box, following factory wiring paths where possible. Secure with cable ties along the full length of each run. Trim the ties flush for a clean finish. In areas where cables may contact sharp edges or moving parts, protect with split conduit.

The kit includes generous cable lengths. Bundle any excess neatly and secure it out of the way.

  1. Mount the Control Box in a dry, protected location close to the battery.
  2. Connect each light's Waterproof Connector to the outputs on the Control Box.
  3. Connect the Battery Terminals: red to positive (inline fuse on positive line), black to negative.

Keyed Connectors

Each Waterproof Connector is keyed and inserts one way only. Align the connector carefully before pushing it in, then thread the waterproof collar until locked. Do not force the connection as misaligned pins will bend or break.

Isolator Switch (Optional)

Route the Isolator Switch cable through the firewall grommet and mount within reach of the driver. Use the switch to kill power to the system when the lights are not in use. If you disconnect the switch pins to feed the cable through the firewall, refit them in the correct order:

Pin Pin Colour Wire Colour Function
Pin 1 Gold Black Negative / Ground
Pin 2 Silver Red Accessory-switched 12V
Pin 3 Silver Blue Constant 12V

Warning: Incorrect pin wiring will cause harness failure.


Step 3: App Pairing

The Spectrum Pro is controlled via the Happy Lighting app — available on iPhone and Android.

  1. Turn on the Isolator Switch.
  2. Download the Happy Lighting app.
  3. Enable Bluetooth on your phone and open the app.
  4. Pair the lights in the app using the device manager in the top left.

From the app you can:

  • Set custom colours and adjust brightness
  • Switch to full 40W white output which is useful as a work light
  • Create and save colour presets
  • Activate Music Mode to synchronise light patterns with audio via the phone's microphone - sensitivity is adjustable
  • Link multiple kits together for synchronised patterns across a full vehicle setup

Specifications

Specification Value
Input Voltage 9–24.2V DC
Power Draw 3.3A @ 12V
Beam Pattern 180° Flood
LEDs per Light 12 x White + 12 x RGBW
Waterproof Rating IP69K
Lens GE Lexan polycarbonate
Bluetooth Range Up to 30m
Warranty 10 years

For installation support, contact the ALTIQ™ team at sales@altiq.com.au or call (03) 9071 2990.
